6 Series Utility TractorsUtility Tractor97/68EC: 77 kW 105 engine hp
6105E / Utility Tractorinfo
6105E / Utility Tractor Details
- Engine HP: 106 Max | 105 Rated
- John Deere FT4 PowerTech™ engine combines performance and fluid economy
- 12/12 or 24/12 hi-lo PowrReverser™ transmission
- Cab, open station, 2WD or MFWD
- 15 degrees of seat swivel with optional air-ride seat
Key Specs
- Engine descriptionJohn Deere PowerTech™ PWL (B20 Diesel Compatible)
- Engine displacement4.5 L
275 cu in. - Rated engine power97/68EC: 77 kW
105 engine hp - Rated PTO power (hp SAE)66 kW
89 PTO hp - Transmission typeStandard: John Deere 12F/12R PowrReverser™ Transmission: 30 km/h
19 mph
Optional: John Deere 24F/12R PowrReverser Transmission: 40 km/h
25 mph - Hydraulic pump rated output36.5 cc pump: 75.7 L/min
20 gpm - Rear hitch category (SAE designation)Category 2: 2500 kg (5500 lb) standard lift at 610 mm behind hitchpoint
Optional: Category 2: 3318 kg (7300 lb) heavy duty lift at 610 mm behind hitchpoint
Engine specifications
- DescriptionJohn Deere PowerTech™ PWL (B20 Diesel Compatible)
- Engine typeDiesel, in-line, 4-cylinders, wet-sleever cylinder lingers with 4 valves-in-head
- Engine familyHJDXL04.5315
- Rated speed2200 rpm
- AspirationTurbocharged, wastegate turbocharger with air-to-air aftercooling and cooled exhaust gas recirculation
- Emission levelFinal Tier 4
- After treatment typeDOC/DPF/SCR
- Displacement4.5 L
275 cu in.
Engine performance
- Rated power97/68EC: 77 kW
105 engine hp - Rated PTO power (hp SAE)66 kW
89 PTO hp - Engine peak torqueAt 1,600 rpm: 432 Nm
318 lb-ft - PTO torque rise30 percent
Transmission
- TypeStandard: John Deere 12F/12R PowrReverser™ Transmission: 30 km/h
19 mph
Optional: John Deere 24F/12R PowrReverser Transmission: 40 km/h
25 mph
Hydraulic system
- TypeOpen-center
Gear driven - Pump rated output36.5 cc pump: 75.7 L/min
20 gpm - Available flow at a single rear SCV75.7 L/min
20 gpm - Number of rear selective control valves (SCVs)Standard: ISO Couplers: 2
Optional: ISO Couplers 3 - SCV controlMechanical
Rear hitch
- Hitch category (SAE designation)Category 2: 2500 kg (5500 lb) standard lift at 610 mm behind hitchpoint
Optional: Category 2: 3318 kg (7300 lb) heavy duty lift at 610 mm behind hitchpoint - Maximum lift capacity behind lift pointsStandard: Category 2 with heavy duty lift: 3318 kg
7300 lb - Sensing typeOptional
Drawbar
- Drawbar categoryStandard: Category 2
Optional: Category 2 heavy duty - Maximum vertical loadStandard: Category 2 1000-1250 kg
2205-2756 lb
Optional: Category 2 heavy duty: 1200-1900 kg
2645-4189 lb
Maximum vertical load dependent on drawbar position
Rear power take-off (PTO)
- TypeIndependent
Standard: 35 mm (1.375 in.) 540 rpm/1000 rpm reversible shaft - Engine rpm (at rated PTO speeds)2085 engine rpm at 540 rpm PTO
2067 engine rpm at 1000 rpm PTO
Front hitch
Rear axle
- TypeFlange
- Final drive typeInboard Planetary
- Rear differential lockFull-locking mechanical
Front axle
- TypeStandard: MFWD
Optional: 2WD - Front axle differential lock2WD: None
MFWD: limited slip
Tires
- Wheel tread range2WD: 1533-2043 mm
60.4-80.4 in.
MFWD: 1516-2016 mm
59.7-79.4 in.
Steering
- TypeStandard: Hydrostatic power
Electrical system
- Alternator size90 amp
- Battery options12 V
- Total cold cranking amps925 CCA
Operator station
- SeatStandard: Mechanical suspension cloth seat
Optional: Air suspension - Instructional seatOptional
- DisplayLCD instrument cluster
Dimensions
- Wheelbase2WD: 2456 mm
96.7 in.
MFWD: 2450 mm
96.5 in. - Approximate shipping weight, Open;Cab2WD: Open: 4064 kg
8960 lb
MFWD: Open: 4268 kg
9410 lb
Cab: 4645 kg
10,240 lb
Weight
- Maximum ballast level6464 kg
14250 lb
Capacities
- Crankcase oil volume15 L
4 U.S. gal. - Fuel tank168 L
44.4 U.S. gal. - Cooling systemOpen station: 18.6 L
4.7 U.S. gal.
Cab: 19.1 L
5 U.S. gal. - Transmission-hydraulic system58 L
15.3 U.S. gal.
Serviceability
- Interval for engine oil change500 hours
- Interval for hydraulic/transmission oil change1,000 hours
- Interval for engine coolant change5,000 hours
Loaders
Precision AG
Miscellaneous
- Country of manufactureMexico
Additional information
- Date collected9-Feb-17
